Alloy Steel Pipe EN10216-2 15NiCuMoNb5-6-4 Round Seamless Boiler
Tubes Large Diameter Size
EN 10002-1, Metallic materials - Tensile testing - Part 1: Method
of test (at ambient temperature).
EN 10002-5, Metallic materials - Tensile testing - Part 5: Method
of testing (at elevated temperature).
EN 10020, Definitions and classification of grades of steel.
EN 10021, General technical delivery requirements for steel and
iron products.
EN 10027-1, Designation systems for steels - Part 1 : Steel names,
principle symbols..
EN 10027-2, Designation systems for steels - Part 2: Numerical
systems.
EN 10045-1, Metallic materials - Charpy impact test - Part 1: Test
method.
EN 10052, Vocabulary of heat treatment terms for ferrous products.
EN 10204, Metallic products - Types of inspection documents.
ENV 10220, Seamless and welded steel tubes - Dimensions and masses
per unit length
EN 10233, Metallic materials - Tubes - Flattening test.
EN 10234, Metallic materials - Tubes - Drift expanding test.
EN 10236, Metallic materials - Tubes - Ring expanding test.
EN 10237, Metallic materials - Tubes - Ring tensile test.
EN 10246-1, Non-Destructive Testing of steel tubes Part 1:
Automatic electromagnetic testing of seamless and welded (except
submerged arc welded) ferromagnetic steel tubes for verification of
hydraulic leak-tightness.
EN 10246-5, Non-Destructive Testing of steel tubes – Part 5:
Automatic full peripheral magnetic transducer/flux leakage testing
of seamless and welded (except submerged arc-welded) ferromagnetic
steel tubes for the detection of longitudinal imperfections.
EN 10246-6, Non-Destructive Testing of steel tubes - Part 6:
Automatic full peripheral ultrasonic testing of seamless steel
tubes for the detection of transverse imperfections.
EN 10246-7, Non-Destructive Testing of steel tubes - Part 7:
Automatic full peripheral ultrasonic testing of seamless and welded
(except submerged arc welded) steel tubes for the detection of
longitudinal imperfections.
EN 10246-14, Non-Destructive Testing of steel tubes - Part 14:
Automatic ultrasonic testing of seamless and welded (except
submerged arc welded) steel tubes for the detection of laminar
imperfections.
EN 10256, Non-Destructive Testing of steel tubes - Qualification
and competence of level 1 and level 2 NDT personnel.
EN ISO 377, Steel and steel products - Location and preparation of
samples and test pieces for mechanical testing (ISO 377:1997)
prEN 10168, Iron and steel products - Inspection documents - List
of information and description.
prEN 10266, Steel tubes, fittings and structural hollow sections -
Symbols and definition of terms for use in product standards
EN ISO 2566-1, Steel - Conversion of elongation values – Part 1:
Carbon and low-alloy steels
(ISO 2566-1:1984)
ISO 14284, Steel and iron - Sampling and preparation of samples for
the determination of chemical composition
CR 10260, Designation systems for steel - Additional symbols
CR 10261, ECISS Information Circular IC 11 - Iron and steel -
Review of available methods of chemical analysis.
Deoxidation process
Steels shall be fully killed.
The tubes shall be manufactured by a seamless process.
Option: The tubes shall be cold finished before heat treatment.
Chemical composition, %
| Grade | C | Si | Mn | P, max | S, max | Cr | Mo | Ni | Al | Cu | Nb | Ti, max | V | Cr+Cu +Mo+Ni | Others |
| P235GH | ≤0.16 | ≤0.35 | ≤1.20 | 0.025 | 0.020 | ≤0.30 | ≤0.08 | ≤0.30 | ≥0.02 | ≤0.30 | ≤0.01 | 0.040 | ≤0.02 | ≤0.70 | - |
| P265GH | ≤0.20 | ≤0.40 | ≤1.40 | 0.025 | 0.020 | ≤0.30 | ≤0.08 | ≤0.30 | ≥0.02 | ≤0.30 | ≤0.01 | 0.040 | ≤0.02 | ≤0.70 | |
| 13CrMo4-5 | 0.10-0.17 | ≤0.35 | 0.40-0.70 | 0.025 | 0.020 | 0.70-1.15 | 0.40-0.60 | ≤0.30 | ≤0.040 | ≤0.30 | - | - | - | - | - |
| 10CrMo9-10 | 0.08-0.14 | ≤0.50 | 0.30-0.70 | 0.025 | 0.020 | 2.00-2.50 | 0.90-1.10 | ≤0.30 | ≤0.040 | ≤0.30 | - | - | - | - | - |
| 15NiCuMoNb5-6-4 | ≤0.17 | 0.25-0.50 | 0.80-1.20 | 0.025 | 0.020 | ≤0.30 | 0.25-0.50 | 1.00-1.30 | ≤0.05 | 0.50-0.80 | 0.015-0.045 | - | - | - | - |
| X10CrMoVNb9-1 | 0.08-0.12 | 0.20-0.50 | 0.30-0.60 | 0.020 | 0.010 | 8.00-9.50 | 0.85-1.05 | ≤0.40 | ≤0.04 | ≤0.30 | 0.06-0.10 | - | 0.18-0.25 | - | N: 0.030-0.070 |
Mechanical properties
| Steel grade | Upper yield strength or proof strength ReH or Rp0,2 for Wall Thickness T min. | Tensile strength Rm | Elongation A min. % |
| T≤16 | 16<T≤40 | 40<T≤60 | 60<T≤100 | | I | T |
| MPa | MPa | MPa | MPa | MPa |
| P235GH | 235 | 225 | 215 | - | 360-500 | 25 | 23 |
| P265GH | 265 | 255 | 245 | - | 410-570 | 23 | 21 |
| 13CrMo4-5 | 290 | 290 | 280 | - | 440-590 | 22 | 20 |
| 10CrMo9-10 | 280 | 280 | 270 | - | 480-630 | 22 | 20 |
| 15NiCuMoNb5-6-4 | 440 | 440 | 440 | 440 | 610-780 | 19 | 17 |
| X10CrMoVNb9-1 | 450 | 450 | 450 | 450 | 630-830 | 19 | 17 |
Minimum proof strength Rp0,2 at elevated temperature
| Steel grade | Wall thickness mm | Minimum proof strength Rp0,2 MPa at temperature of °C |
| 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 550 | 600 |
| P235GH | ≤60 | 198 | 187 | 170 | 150 | 132 | 120 | 112 | 108 | - | - | - |
| P265GH | ≤60 | 226 | 213 | 192 | 171 | 154 | 141 | 134 | 128 | - | - | - |
| 13CrMo4-5 | ≤60 | 264 | 253 | 245 | 236 | 192 | 182 | 174 | 168 | 166 | - | - |
| 10CrMo9-10 | ≤60 | 249 | 241 | 234 | 224 | 219 | 212 | 207 | 193 | 180 | - | - |
| 15NiCuMoNb5-6-4 | ≤80 | 422 | 412 | 402 | 392 | 382 | 373 | 343 | 304 | - | - | - |
| X10CrMoVNb9-1 | ≤100 | 410 | 395 | 380 | 370 | 360 | 350 | 340 | 320 | 300 | 270 | 215 |
Appearance
1 The tubes shall be free from external and internal surface
defects that can be detected by visual examination.
2 The internal and external surface finish of the tubes shall be
typical of the manufacturing process and, where applicable, the
heat treatment employed. Normally the finish and surface condition
shall be such that any surface imperfections requiring dressing can
be identified.
3 It shall be permissible to dress, only by grinding or machining,
surface imperfections provided that, after doing so, the wall
thickness in the dressed area is not less than the specified
minimum wall thickness. All dressed areas shall blend smoothly into
the contour of the tube.
4 Any surface imperfection, which is demonstrated to be deeper than
5 % of the wall thickness T or 3 mm whichever is the smaller, shall
be dressed. This requirement does not apply to surface imperfection
with a depth equal or less 0,3 mm
5 Surface imperfections which encroach on the specified minimum
wall thickness shall be considered defects and tubes containing
these shall be deemed not to conform to this Part of EN 10216.
Leak Tightness
The tubes shall pass a hydrostatic test (see 11.8.1) or
electromagnetic test for leak-tightness.
Content of inspection documents
The content of the inspection document shall be in accordance with
prEN 10168.
The inspection certificate or inspection report shall contain the
following codes and information:
- commercial transactions and parties involved;
- description of products to which the inspection document applies;
- direction of the test pieces and testing temperature;
- tensile test;
- impact test if applicable;
- other tests (e.g. flattening);
- chemical composition on cast analysis (product analysis if
applicable);
- marking and identification, surface appearance, shape and
dimensional properties;
- leak-tightness test, NDT, material identification if applicable;
Test methods
1 Chemical analysis
2 Tensile test
2.1 tensile test at room temperature in accordance with EN 10002-1
2.2 tensile test at elevated temperature in accordance with EN
10002-5
3 Flattening test in accordance with EN 10233
4 Ring tensile test in accordance with EN 10237
5 Drift expanding test in accordance with EN 10237
6 Ring expanding test in accordance with EN 10236
7 Impact test in accordance with EN 10045-1
8 Leak tightness test
8.1 Hydrostatic test
8.2 Electromagnetic test in accordance with EN 10246-1
9 Dimensional inspection
10 Visual examination
11 Non-destructive test
| Place of Origin | China | Brand Name | BOYUE |
| Standard | ANSI, ISO, ASME, DIN, ASTM | Type | Seamless |
| ModelNumber | Alloy Steel Pipe | Thickness | SCH 5-SCH XXS |
| Packing | Depending on customer | Payment | 30%TT+70% Balance |
Supply Ability:40000Pieces / per Month
Packaging & Delivery
Packaging Details:Generally plywooden case or following customer's
requirement.
Port:Shanghai/Tianjin
Commerce Clause
| Minimum Order Quantity: | 1pcs |
| Price: | Depending on quantity |
| Payment Terms: | T/T or Western Union or LC |
| Supply Ability: | 40000 ton per month |
| Delivery Time: | 10-100 days depending on quantity |
| Packaging Details: | Depending on customer |
